Axial Flow Air Fan
Specifications
Air Fan - Explosion Proof Fan
Confined Space Hazard Prevention
|
Explosion-proof air fans are necessities for ventilation, exhaust and cooling of climate in hazardous environments (flammable, volatile material working area, mine, high temperature, hazardous atmosphere). It is used for extraction of hazardous, overheated and contaminated air and the supply and distribution of fresh air in amounts necessary to provide safe and comfortable conditions for the occupants of the space being ventilated. Applying to offices and workshops means the creation of an environment which stimulates the worker to higher efficiency and safety. We have many types of air fans in stock.
|
Axial-flow Air Fan
(18" Air Fan)
|
|
|
|
|
with reversible control
|
|
Model
|
TR-18P
|
TR-18PT
|
TR-18AL
|
TR-18ALT
|
TR-18ALTR
|
|
Blade Material
|
P.P.
|
P.P.
|
Aluminium
|
Aluminium
|
Aluminium
|
|
F.R.L
|
Χ
|
|
Χ
|
|
|
|
Width (mm)
|
248
|
|
Height (mm)
|
525
|
|
Height (add toe) mm
|
600
|
|
Flow Rate (m3/h)
|
4,400
|
|
Flow Velocity (m/s)
|
1.5
|
|
Net Weight (kg)
|
17
|
17.7
|
17.5
|
18.4
|
19.1
|
|
Gross Weight (kg)
|
18
|
18.7
|
18.5
|
19.4
|
20.1
|
|
Axial-flow Air Fan
(24" Air Fan)
|
|
|
with reversible control
|
|
Model
|
TR-24AL
|
TR-24ALT
|
TR-24ALTR
|
|
Blade Material
|
Aluminium
|
|
F.R.L
|
Χ
|
|
|
|
Width (mm)
|
310
|
|
Height (mm)
|
680
|
|
Height (add toe) mm
|
760
|
|
Flow Rate (m3/h)
|
5,900
|
|
|
1.5
|
|
Net Weight (kg)
|
24
|
25.5
|
26.2
|
|
Gross Weight (kg)
|
24.5
|
27
|
27.7
|
Model: TR (Exhaust-Ventilation Axial Flow)
Sizes Available: 10", 12", 14", 16", 18" & 24"
- Size: TG12
Fan Height Including Feet (mm): 390
Fan Thickness (mm): 218
Fan Diameter: 12"
- Size: TG18
Fan Height Including Feet (mm): 600
Fan Thickness (mm): 248
Fan Diameter: 24"
- Size: TG24
Fan Height Including Feet (mm): 760
Fan Thickness (mm): 310
Fan Diameter: 24"
Contact us for Information on other sizes not listed above.
Air Fan Features Overview:
- Complete Safety.
- 100% Explosion Proof.
- Simple Stepless Speed Control.
- Hermetically sealed to prevent dirt & dust.
- No sparks or heat build up when blade is impeded.
- Perfect ventilation solution for any hazardous environment.
Working Fluid : Compressed Air Operating Pressure : 6 kg /cm2 (85 PSI)
Ambient Temperature : -10 ~ +120 deg. C Max.Operating Pressure : 7 kg /cm2 (100 PSI)
Air Fans are designed to operate by compressed air and to be used with F.R.L.(filter, regulator and lubricator) to improve performance and provide longer life.
Users should be responsible for determining suitability of the product for intended use and assuming all risk and liability whatsoever in connection therewith.
