  Air Motors Technology   >   Air Mixers - Explosion proof   >   Air Mixer (20L Drums)


  Air Mixer (20L Drums)

No Image


No Image


No Image


TONSON Australia has many years in mixing technology solutions for all industries meeting Australian standards; many types are available including Mobile 20L Mixers, we can supply mixers to suit explosion proof and standard environments. Electric types also avilable.

Mobile air lift mixer
air mixer
Durable, Rust-proof Base
Stainless Steel
Mobile Air Lift Mixer
Mobile Air Lift Mixer
Mobile Air Lift Mixer
Model
TB-M3-S
TB-M3
TB-M4
TB-M5
Power
1/4HP
1/4HP
1/3HP
1/2HP
Shaft
Ø16mm x 520mm
Ø16mm x 520mm
Propeller
6" x 1
6" x 1
6" x 1
8" x 1
Net Weight (kg)




Gross Weight (kg)





Features of the above Air Mixers Include:

  • Remove air motor off stand after loosening clamp set screw.
  • Insert motor shaft into 2” opening and adjust for preferred angle for mixing.
  • Suitable for mixing 5 Gal (20L).
  • Tank or drums up to 40cm diameter.
  • Elevation of mixer may be pneumatically adjusted.
  • Many Propellers and Impellers available


Mobile air lift mixer

air mixer
Mobile air lift mixer with handle and casters
Model
TB-V2
TB-V4
Power
0.93HP
1.71HP
Shaft
Ø12mm x 520mm
Ø16mm x 520mm
Propeller
6" x 1
8" x 1
Net Weight (kg)


Gross Weight (kg)



Mobile air lift mixer with handle and casters
 air mixer
Durable, Rust-proof Base
Stainless Steel
air mixer
air mixer
Model
TB-1-M3-S
TB-1-M3
TB-1-M4
TB-1-M5
Power
1/4HP
1/4HP
1/3HP
1/2HP
Shaft
Ø16mm x 520mm
Ø16mm x 520mm
Propeller
6" x 1
6" x 1
6" x 1
8" x 1
Net Weight (kg)




Gross Weight (kg)



26

Mobile air lift mixer with handle and casters
Mobile air lift mixer with handle and casters
Mobile air lift mixer with handle and casters
Model
TB-1-V2
TB-1-V4
Power
0.93HP
1.71HP
Shaft
Ø12mm x 520mm
Ø16mm x 520mm
Propeller
6" x 1
8" x 1
Net Weight (kg)


Gross Weight (kg)



Features of the following Mixers Include:

  • Manual Lift Bench Mixer -SUS (Acid Resistance)
  • Fully constructed out of stainless steel.
  • Manual elevation adjustment.
  • Suitable for pharmaceutical, food, volatile and chemical industry.
  • Manual Lift Bench Mixer
  • Suitable for mixing 20 liters tank or drums up to 40cm diameter. Elevation of the mixer may be manually adjusted.
  • Many Propellers and Impellers available

lift mixer
Hand hold lift mixer


Hand hold lift mixer
Hand hold lift mixer


Hand Hold Lift Mixer
Model
TS-HA-M1
TS-HA-M2
TS-HA-M3
TS-HA-M4
TS-HA-M5
Power
1/8HP
1/6HP
1/4HP
1/3HP
1/2HP
Shaft
Ø12mm x 550mm
Ø16mm x 550mm
Propeller
6" x 1
6" x 1
6" x 1
6" x 1
8" x 1
Net Weight (kg)





Gross Weight (kg)



19.5


21.5

Hand hold lift mixer

Hand hold lift mixer
Hand hold lift mixer
Model
TS-HA-V2
TS-HA-V4
Power
0.93HP
1.71HP
Shaft
Ø12mm x 550mm
Ø16mm x 550mm
Propeller
6" x 1
8" x 1
Net Weight (kg)


Gross Weight (kg)



Extendable air mixer

Extendable air mixer






Model
TS-5T-M1
TS-5T-M2
TS-5T-M3
TS-5T-M4
TS-5T-M5
Power
1/8HP
1/6HP
1/4HP
1/3HP
1/2HP
Shaft
Ø16mm x 520mm
Propeller
6" x 1
6" x 1
6" x 1
6" x 1
8" x 1
Net Weight (kg)










Gross Weight (kg)




21






Extendable air mixer


Model
TS-5T-V2
TS-5T-V4
Power
0.93HP
1.71HP
Shaft
Ø16mm x 520mm
Ø16mm x 520mm
Propeller
6" x 1
8" x 1
Net Weight (kg)


Gross Weight (kg)



Features of the following Air Mixers Include:

  • Suitable for mixing (20L) 5 gallon square and round tanks.
  • Simply place container under four leg stand to start mixing application.
  • Stepless speed control may be adjusted freely.
  • Many Propellers and Impellers available

stand air mixer
Stand Air Mixer

Stand Air Mixer
Stand Air Mixer

Stand Air Mixer

High Power Stand Air Mixer

Model
TS-5A-M1
TS-5A-M2
TS-5A-M3
TS-5A-M4
TS-5A-M5
Power
1/8HP
1/6HP
1/4HP
1/3HP
1/2HP
Shaft
Ø12mm x 420mm
Ø16mm x 420mm
Propeller
6" x 1
6" x 1
6" x 1
6" x 1
8" x 1
Net Weight (kg)










Gross Weight (kg)
6.5



7






Four legs stand air mixer
Four legs stand air mixer
Model
TS-5A-V2
TS-5A-V4
Power
0.93HP
1.71HP
Shaft
Ø12mm x 420mm
Ø16mm x 420mm
Propeller
6" x 1
8" x 1
Net Weight (kg)


Gross Weight (kg)



  Call our Australian Head Office Ph: 02 9607 4100 or email us:
sales@tonson-motor.com.au
for any enquiries or questions on all Air Mixers.
